$25,850.00
Specifications
MODEL NUMBER: 23-0406
| sku | 23-0406 |
| capacity in mild steel | 4 mm x 2550 mm |
| roll diameter (top) | 180 mm |
| motorised power pitch adjustment | standard |
| motor power | 4 / 415 kw/V |
| dimensions (l x w x h) | 4150 mm x 950 mm x 1300 mm |
| weight (nt) | 2970 kg |
SM-S2504 Plate Curving Roller. Steelmaster 2500mm x 4mm Capacity. Motorised Pinch Type Operation
Save $$$ On Limited Floor Stock Super Savings – Once It’s Gone, It’s Gone ! So is the $20000 Tax Break – Ends June 30 $$
These upmarket rollers offer many features you would normally expect to find on more expensive rollers. Digital pendant control, motorized pinch roller with roller offset, cone rolling attachment and more.
Features
❚ quality certified steel rolls with high tensile strength
❚ initial pinch asymmetrical roller
❚ conical bending device
❚ motorised rear roller
❚ digital readout display fitted
❚ rigid construction for precise and smooth operation and long life usage
❚ the top roll can be swivelled outward for easy removal of the finished work piece
❚ foot switch control for forward / reverse. encased in a protective housing
❚ central lubrication system
❚ manufactured to CE standard
Technical Data
❚ capacity -2550mm x 4.0mm mild steel
❚ initial pinch asymmetrical roller
❚ digital readout display fitted
❚ top roller diameter – 160mm
❚ 4.0kw – 415 volt
❚ dimensions – 4050mm x 950mm x 1300mm
❚ weight – 2970kg
