Specifications
MODEL NUMBER: 15-0345
| sku | 15-0345 | |
| cutting capacities ø (w x h x t) | ||
| 90° | 1200 mm | |
| ○ | 60° | N/A |
| 45° | N/A | |
| 90° | 1200 mm x 1200 mm | |
| □ | 60° | N/A |
| 45° | N/A | |
| 90° | 1200 mm x 1200 mm | |
| ▯ | 60° | N/A |
| 45° | N/A | |
| ■● | 90° | 1200 mm |
| beam return | Hydraulic type | |
| blade size (l x w x t) | 10800 mm x 67 mm x 1.6 mm | |
| speed range | 15 ~ 80 (Inverter) m/min | |
| table working height | 700 mm | |
| motor power | 15 / 415 kw/V | |
| dimensions (l x w x h) | 4950 mm x 2200 mm x 3150 mm | |
| weight (nt) | 12000 kg |
Features
❚ large double columns precision ground for additional support
❚ power assisted work table
❚ hydraulic blade tensioner
❚ hydraulic vice clamping
❚ variable hydraulic down feed & auto return
❚ automatic chip conveyor
❚ carbide & bearing blade guides
❚ breakage sensor
❚ powered brush cleaner
❚ centralized control panel
❚ powered in feed roller table 1000mm in length
❚ laser guide
❚ coolant
❚ halogen work light
❚ one piece bi metal blade fitted
❚ CE compliance
❚ tool kit
