Steelmaster Industrial
Anti-Spark Arrestor for CLEARMASTER SM-SHF-30 Fume System
Regular price
$10,850.00
Unit price
Unavailable
Replacement anti-spark arrestor for the CLEARMASTER SM-SHF-30 spark and fume extraction system (3600m/Hr).
Technical Data
Model: SM-SHF-30
Extraction Type – Spark, Small Parts, Grinding, Polishing, Welding, Smoke, Fume, Dust
Air Volume – 3600m3/Hr
Max. Pressure (Pa) – 2400Pa
Work Table Size: 800mm x 670mm (Other sizes available – 1550mm & 2100mm Wide)
Filter Material – PTFE Coated Folded Cartridge
Filter Installation – Vertical
Filter Area – 22m3
Filter Efficiency – 99.9%
Compressed Air – 0.5 ~ 0.6Mpa
Solenoid Valves – 2 off
Extra replaceable Vertical Filters & Spark Arrestors – Available
Dimensions – 800mm x 1100mm x 1900mm x 280Kg
Power – 3Kw – 415V
Stock Ordering Code – 21-0807
Product Features
Stainless steel grinding table, easy to access with rear pull out waste draw
SIEMENS motor, Schneider electrical control.
Auto pulse back flushing, filter easily with high effect.
Top mounted Exhaust
LED lamp, 240Volt power point with added usb point
Powder coated frame
Lockable castor wheels
